SV01N_13418587 EN/DE/ES/FR/IT/PT
This documentation applies to the SMV frequency inverter and contains important technical data regarding the
installation, operation, and commissioning of the inverter.
These instructions are only valid for SMV frequency inverters with software revision 4.23 or higher
For version 4.23 software, the drive nameplate illustrated below would show “42” in the “F” location.
Please read these instructions in their entirety before commissioning the drive.
C A B D E F
Type:
ESV751N04TXB
Id-No: 00000000
INPUT:
3~ (3/PE)
400/480 V
2.9/2.5 A
50-60 HZ
OUTPUT:
3~ (3/PE)
0 - 400/460 V
2.4/2.1 A
0.75 KW/1HP
0 - 500 HZ
For detailed information
refer to instruction
Manual: SV01
000000000000000000
ESV751N04TXB000XX####
TYPE-4X INDOOR USE ONLY
A B C D E F
Certifications Type Input Ratings Output Ratings Hardware Version Software Version
Scope of delivery Important
• 1 SMV Inverter
with EPM installed (see Section 4.4)
• 1 Operating Instructions manual
After receipt of the delivery, check immediately whether the items delivered match
the accompanying papers. Lenze AC Tech does not accept any liability for deficiencies
claimed subsequently.
Claim:
• visible transport damage immediately to the forwarder.
• visible deficiencies /incompleteness immediately to your Lenze AC Tech representative
Related Documents
The documentation listed herein contains information relevant to the operation of the SMVector frequency inverter. To obtain the latest
documentation, visit the Technical Library at Lenze website.
Document # Description
CMVINS01 SMVector Communications Module Installation Instruction
CMVMB401 SMVector ModBus RTU over RS485 Communications Reference Guide
CMVLC401 SMVector Lecom Communications Reference Guide
CMVCAN01 SMVector CANopen Communications Reference Guide
CMVDVN01 SMVector DeviceNet Communications Reference Guide
CMVETH01 SMVector EtherNet/IP Communications Reference Guide
CMVPFB01 SMVector PROFIBUS Communications Reference Guide
ALSV01 SMVector Additional I/O Module Installation and Operation Manual
DBV01 SMVector Dynamic Braking
PTV01 SMVector Potentiometer Install Instructions
RKV01 SMVector ESVZXK1 Remote Keypad
RKVU01 SMVector ESVZXH0 Remote Keypad (for NEMA 1 15-60HP (11-45kW) Drives)
About These Instructions
Copyright © 2006 Lenze AC Tech Corporation
All rights reserved. No part of this manual may be reproduced or transmitted in any form without written permission from Lenze AC Tech
Corporation. The information and technical data in this manual are subject to change without notice. Lenze AC Tech Corporation makes no
warranty of any kind with respect to this material, including, but not limited to, the implied warranties of its merchantability and fitness for a
given purpose. Lenze AC Tech Corporation assumes no responsibility for any errors that may appear in this manual.
All information given in this documentation has been carefully selected and tested for compliance with the hardware and software described.
Nevertheless, discrepancies cannot be ruled out. Lenze AC Tech does not accept any responsibility nor liability for damages that may occur.
Any necessary corrections will be implemented in subsequent editions. This document is printed in the United States
