54
SV01N_13418587 EN/DE/ES/FR/IT/PT
Commissioning
4.5.9.1 Sequencer Flow Diagram Left
Drive Stop/Start Control
TB-13C
TB-13B
TB-13A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
P701
P702
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
P703
P121
24
P122
24
P123
24
3
2
3
P700
0
2
Sequencer
mode
disabled
1
Start
Segment
Start
Segment
Start
Segment
“Start Segment” number selection
WARNING
If none of the digital inputs (TB-13A,B,C or D) are asserted
but a start signal is given from the Start/Stop source (P100)
then the drive will run at the output frequency value governed by
the frequency reference source (P101).
Start from
Local Keypad
Start from
Terminal Strip
0
1
2
(2)
P100
Start from
Remote Keypad
3
(1)
Start from Network
(SMV communications
module)
Notes
(1)
Refer to relevant communications module user guide for starting from a
communications network, RS485 etc..
(2)
Refer to P100 description in the SMV Operating instructions for further
combinations of start sources.
> Selections shown as default values
Digital Input priority:
TB-13A -Lowest
TB-13B
TB-13C
Sequencer Flow Diagram
TB-13D
24
P124
P704
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Segment
Start
TB-13D - Highest
(3)
TB-13D available on SMV models rated 15HP (11kW) or greater.
(3)
WARNING
If the input defined to “Start Sequence” is opened during a sequence, the drive will exit sequencer
mode and will run at the specified standard or alternate speed source (dependent on drive
configuration).
To Next Page
