5
SV01N_13418587 EN/DE/ES/FR/IT/PT
Safety Information
Harmonics Notification in accordance with EN 61000-3-2, EN 61000-3-12:
Operation in public supply networks (Limitation of harmonic currents i.a.w. EN 61000-3-2, Electromagnetic Compatibility
(EMC) Limits). Limits for harmonic current emissions (equipment input current up to 16A/phase).
Directive Total Power
connected to Mains
(public supply)
Additional Measures Required for Compliance
(2)
EN 61000-3-2
< 0.5kW with mains choke
0.5 ... 1kW with active filter
> 1kW complies without additional measures
EN 61000-3-12
16 ... 75amp Additional measures are required for compliance with the standard
(1) For compliance with EMC regulations, the permissable cable lengths may change.
(2) The additional measures described only ensure that the controller meets the requirements of the EN 61000-3-2.
The machine/system manufacturer is responsible for the machine’s compliance with the regulations.
Safety Information in accordance with EN 61800-5-1:
DANGER! Hazard of Electrical Shock
Capacitors retain charge for approximately 180 seconds after power is removed. Allow at least
3 minutes for discharge of residual charge before touching the drive.
WARNING!
• This product can cause a d.c. current in the PE conductor. Where a residual current-operated (RCD) or
monitoring (RCM) device is used for protection in case of direct or indirect contact, only an RCD or RCM
Type B is allowed on the supply side of this product.
• Leakage Current may exceed 3.5mA AC. The minimum size of the PE conductor shall comply with local
safety regulations for high leakage current equipment.
• In a domestic environment, this product may cause radio interference in which case supplementary
mitigation measures may be required.
NOTE
Control and communications terminals provide reinforced insulation (i.e. considered SELV or PELV, providing
protection in case of direct contact) when the drive is connected to a power system rated up to 300VAC between
phase to ground (PE) and the applied voltage on Terminals 16 and 17 is less than 150VAC between phase to
ground. Otherwise, control and communications terminals provide basic insulation.
Safety Information in accordance with UL:
Note for UL approved system with integrated controllers: UL warnings are notes which apply to UL systems. The
documentation contains special information about UL.
Warnings!
•Suitable for use on a circuit capable of delivering not more than 200,000 rms symmetrical amperes, at
the maximum voltage rating marked on the drive.
•Use minimum 75 °C copper wire only.
•Shall be installed in a pollution degree 2 macro-environment.
•NEMA 1 (IP31) models shall be installed in a pollution degree 2 macro-environment.
•All models are suitable for installation in a compartment handling Conditioned Air (i.e., plenum rated).
Torque Requirements (in accordance with UL) are listed in section 3.2.1, Power Connections.
