Lexicon MC-12 User Manual

Lexicon
MC-12 Serial Communications Protocol Printed on: 07/13/05
Additional Ir Codes(V5.0)
Mode Code(hex) Mode Code(hex)
DIRECT_LOGIC7_IR 0xAC DIRECT_DTS_LOGIC7_IR 0xEC
DIRECT_TV_LOGIC_IR 0xAD DIRECT_DTS_MUSIC_IR 0xED
DIRECT_MUSIC_LOGIC_IR 0xAE DIRECT_DTS_2CHANNEL_IR 0xEE
DIRECT_2CHAN_SURROUND_IR 0xAF DIRECT_DTS_IR 0xEF
DIRECT_2_CHANNEL_IR 0xB0 DIRECT_DTS_THX_IR 0xF0
DIRECT_MONO_LOGIC_IR 0xB1 DIRECT__51_AD_FILM_IR 0xF1
DIRECT_MONO_SURROUND_IR 0xB2 DIRECT__51_AD_MUSIC_IR 0xF2
DIRECT_MONO_IR 0xB3 DIRECT__51_AD_2CHANNEL_IR 0xF3
DIRECT_PROLOGIC_IR 0xB4 DIRECT__51_AD_IR 0xF4
DIRECT_PROLOGIC2_IR 0xB5 DIRECT__51_AD_THX_IR 0xF5
DIRECT_PL2MUSIC_IR 0xB6 DIRECT_NIGHTCLUB_IR 0xF6
DIRECT_THX_CINEMA_IR 0xB7 DIRECT_CONCERT_HALL_IR 0xF7
DIRECT_DTS_NEO_FILM_IR 0xB8 DIRECT_CHURCH_IR 0xF8
DIRECT_DTS_NEO_MUSIC_IR 0xB9 DIRECT_CATHEDRAL_IR 0xF9
DIRECT__51_LOGIC7_IR 0xBA DIRECT_MUSIC_SURR_IR 0xFA
DIRECT__51_TV_LOGIC_IR 0xBB DIRECT__51_AD_THX_MUSIC_IR 0xFB
DIRECT__51_MUSIC_IR 0xBC DIRECT_DTS_THX_MUSIC_IR 0xFC
DIRECT__51_THX_IR 0xBD DIRECT__51_THX_MUSIC_IR 0xFD
DIRECT_DOLBY_DIGITAL_IR 0xBE DIRECT_PANORAMA_IR 0xFE
DIRECT__51_2CHANNEL_IR 0xBF
DIRECT__51_MONO_LOGIC_IR 0xC0 DIRECT_PLIIX_THX 0xCB
DIRECT__51_MONO_SURROUND_IR 0xC6 DIRECT_PLIIX_MOVIE 0xCC
DIRECT__51_MONO_IR 0xC7 DIRECT_PLIIX_MUSIC 0xCD
DIRECT_5_1PLIIX_MOVIE 0xCE
DIRECT_5_1_PLIIX_MUSIC 0xCF
Appendix E MC-1 Input Id’s
Input Name
Input Id
0
Tape
Tuner
1
Cd
2
Aux
3
TV
4
V-Disc
5
DVD
6
VCR
7
Appendix F MC-12 Input Ids
MC-12
Input Name
MC-12
Input Id
Mapped
MC-1
Input Name
OFF 0
N/A
DVD1 1
Aux
DVD2 2
Aux
LD 3
V-Disc
TV 4
TV
SAT 5
Aux
VCR 6
VCR
CD 7
CD
© 2005 Harman Specialty Group All rights reserved. 60 of 106
