Lexicon
MC-12 Serial Com
municati
ons Protocol
Printed on: 07/13/
05
Appendix J MC-12 M
ode Ids
MC-12 Mode ID
MC-12 Mode Name
0 NONE
1 N/A
2 Internal
Noise
3 L7
Film
4 L7
TV
5 L7
Music
6 2-Ch
Surround
7 2-Channel
8 Mono
Logic
9 Mono
Surround
10 Mono
11 Pro
Logic
12 Prologic
II
13 PLII
Music
14 THX
Cinema
15
Dts Neo6 Film
16
Dts Neo6 Music
17
5.1 L7 Film
18
5.1 L7 TV
19
5.1 L7 Music
20 5.1
THX(ex)
21 Dolby
Digital(Ex)
22 5.1
2-Channel
23
5.1 Mono Logic
24
5.1 Mono Surround
25 5.1
Mono
26
dts L7 Film
27
dts L7 Music
28 dts
2-Channel
29 dts
Film
30 dts
THX
31
2ch Analog Bypass
32
5.1 Analog Bypass
33
External Noise PLII
34
External Noise Dolby Digital
35
External Noise dts
36
5.1a L7 Film
37
5.1a L7 Music
38 5.1a
2-Channel
39 5.1a
Standard
40 5.1a
THX
41 NightClub
42 Concert
Hall
43 Church
44 Cathedral
45
L7 Music Surround
© 2005 Harman Specialty Group All rights reserved.
64 of 106
63
65
Table of Contents
Default Chapter
4
Table of Contents
4
1 Documents
7
Change List
7
2 Definitions
7
Protocol Version Cross-Reference
8
3 Abbreviations
8
4 General Description
8
5 Physical Layer
10
DB-9 RS232 Connector
10
Serial Port Driver
10
Errors
10
MC-12 Receive Buffer
10
MC-12 Hardware Verification (V1.10, Not Supported in MC-12 V1.00, V1.01)
10
6 Data Link Layer
11
Errors
11
7 Application Layer
12
MC-12 Asynchronous Notification Packets
12
Wakeup Notification (MC-12, MC-1)
12
Sleep Notification (MC-12, MC-1)
12
Front Panel Display (MC-12, MC-1)
12
MC-1 Parameter Change (MC-12, MC-1)
13
MC-12 Parameter Notification by ID (MC-12)
15
Acknowledgment Packets
16
Acknowledge (MC-12, MC-1)
16
No Acknowledge (MC-12, MC-1)
17
Host Initiated Command Packets
17
Reset Unit (MC-12, MC-1)
17
Restore (MC-12, MC-1)
17
MC-1 Send IR Command (MC-12, MC-1)
18
Get Unit Configuration (MC-12, MC-1)
18
Get System Status (MC-12, MC-1)
21
Get Zone 2 Status (MC-12, MC-1)
23
Get System Parameter Definition (MC-1)
24
Get System Parameter Values (MC-1)
24
Get Effect Definition by ID (MC-1)
24
Get Effect Parameter Definition (MC-1)
24
Get Effect Parameter Values (MC-1)
24
Get Custom Name (MC-12, MC-1)
24
Get Input Name by ID (MC-12, MC-1)
25
Get FPD Control Registers (MC-1)
25
Set System Parameter Values (MC-1)
26
Set Effect Parameter Values (MC-1)
26
Set Effect Name by Effect ID (MC-1)
26
Set System Volume (MC-12, MC-1)
26
Set Main Balance (MC-12, MC-1)
26
Set Front/Back Balance (MC-12, MC-1)
27
Set Active Effect by ID (MC-12, MC-1)
28
Set Record Input (MC-12, MC-1)
28
Clear Record Input (MC-12, MC-1)
29
Set Zone2 Volume (MC-12, MC-1)
29
Set Zone2 Left/Right Balance (MC-12, MC-1)
30
Set Custom Name (MC-12, MC-1)
31
Set Input Name by ID (MC-12, MC-1)
31
Set FPD Control Registers (MC-1)
32
Host Wakeup (MC-12, MC-1)
32
Host Sleep (MC-12, MC-1)
33
Get Communication Configuration (MC-12, MC-1)
33
Set Communication Configuration (MC-12, MC-1)
34
Set Mute (MC-12, MC-1)
34
Set Output Level Adjustments (MC-1)
35
Send Display String Command (MC-12, MC-1)
35
MC-12 Get Parameter Definition by ID (MC-12)
36
MC-12 Set Parameter Value by ID (MC-12)
38
MC-12 Set Parameter Value by ID, no Run (MC-12)
40
MC-12 Get Unit Configuration (MC-12)
40
MC-12 Send IR Command (MC-12)
43
MC-12 Get Parameter Value by ID (MC-12)
43
MC-12 Set Parameter Notification by ID (MC-12)
44
MC-12 Parameter Get Value String by ID (MC-12)
45
MC-12 Clear All Parameter Notifications (MC-12)
46
MC-12 Get System Status (MC-12)
46
MC-12 Get Record Status (MC-12)
48
MC-12 Set System Volume (MC-12)
49
MC-12 Set Main Balance (MC-12)
49
MC-12 Set Front/Back Balance (MC-12)
50
MC-12 Set Active Effect by ID (MC-12)
50
MC-12 Set Record Input (MC-12)
51
MC-12 Set Zone2 Volume (MC-12)
52
MC-12 Set Zone2 Left/Right Balance (MC-12)
52
MC-12 Get Input Name by ID (MC-12)
53
MC-12 Set Input Name by ID (MC-12)
54
Appendix A Command Codes
55
Appendix B Error Codes
57
Appendix C DC-2, MC-1 IR-Codes
58
Appendix D MC-12 IR Codes
59
Appendix E MC-1 Input ID's
60
Appendix F MC-12 Input Ids
60
Appendix G Protocol Constants
61
Appendix H MC-12 to MC-1 Effect Map
62
Appendix I MC-1 to MC-12 Effect ID Map
63
Appendix J MC-12 Mode Ids
64
Application Notes and Examples
65
Box Initializations
65
MC-12
65
Host
65
Getting System Wide Status and Setup
65
Downloading the System Setup to the
65
Simple System Control & System Status
65
Examples
67
MC-12 Get Unit Configuration
67
Send MC-1 IR Command Example
68
Send MC-12 IR Command Example
69
