Lexicon
MC-12 Serial Com
municati
ons Protocol
Printed on: 07/13/
05
PVR 8
Aux
GAME 9
Aux
TAPE 10
TAPE
TUNER 11
TUNER
AUX 12
AUX
Appendix G Protocol Constants
Constant Value
(Dec)
Units
FPD_LINE_LENGTH 20
Chars
PARAM_NAME_LENGTH 13
Chars
CUSTOM_NAME_LENGTH 20
Chars
INPUT_NAME_LENGTH 8
Chars
PARAM_PATH_LENGTH
80
Chars
INTER_PACKET_TIME 200
mSec
SOP 0xF1
Hex
EOP 0xF2
Hex
© 2005 Harman Specialty Group All rights reserved.
61 of 106
60
62
Table of Contents
Default Chapter
4
Table of Contents
4
1 Documents
7
Change List
7
2 Definitions
7
Protocol Version Cross-Reference
8
3 Abbreviations
8
4 General Description
8
5 Physical Layer
10
DB-9 RS232 Connector
10
Serial Port Driver
10
Errors
10
MC-12 Receive Buffer
10
MC-12 Hardware Verification (V1.10, Not Supported in MC-12 V1.00, V1.01)
10
6 Data Link Layer
11
Errors
11
7 Application Layer
12
MC-12 Asynchronous Notification Packets
12
Wakeup Notification (MC-12, MC-1)
12
Sleep Notification (MC-12, MC-1)
12
Front Panel Display (MC-12, MC-1)
12
MC-1 Parameter Change (MC-12, MC-1)
13
MC-12 Parameter Notification by ID (MC-12)
15
Acknowledgment Packets
16
Acknowledge (MC-12, MC-1)
16
No Acknowledge (MC-12, MC-1)
17
Host Initiated Command Packets
17
Reset Unit (MC-12, MC-1)
17
Restore (MC-12, MC-1)
17
MC-1 Send IR Command (MC-12, MC-1)
18
Get Unit Configuration (MC-12, MC-1)
18
Get System Status (MC-12, MC-1)
21
Get Zone 2 Status (MC-12, MC-1)
23
Get System Parameter Definition (MC-1)
24
Get System Parameter Values (MC-1)
24
Get Effect Definition by ID (MC-1)
24
Get Effect Parameter Definition (MC-1)
24
Get Effect Parameter Values (MC-1)
24
Get Custom Name (MC-12, MC-1)
24
Get Input Name by ID (MC-12, MC-1)
25
Get FPD Control Registers (MC-1)
25
Set System Parameter Values (MC-1)
26
Set Effect Parameter Values (MC-1)
26
Set Effect Name by Effect ID (MC-1)
26
Set System Volume (MC-12, MC-1)
26
Set Main Balance (MC-12, MC-1)
26
Set Front/Back Balance (MC-12, MC-1)
27
Set Active Effect by ID (MC-12, MC-1)
28
Set Record Input (MC-12, MC-1)
28
Clear Record Input (MC-12, MC-1)
29
Set Zone2 Volume (MC-12, MC-1)
29
Set Zone2 Left/Right Balance (MC-12, MC-1)
30
Set Custom Name (MC-12, MC-1)
31
Set Input Name by ID (MC-12, MC-1)
31
Set FPD Control Registers (MC-1)
32
Host Wakeup (MC-12, MC-1)
32
Host Sleep (MC-12, MC-1)
33
Get Communication Configuration (MC-12, MC-1)
33
Set Communication Configuration (MC-12, MC-1)
34
Set Mute (MC-12, MC-1)
34
Set Output Level Adjustments (MC-1)
35
Send Display String Command (MC-12, MC-1)
35
MC-12 Get Parameter Definition by ID (MC-12)
36
MC-12 Set Parameter Value by ID (MC-12)
38
MC-12 Set Parameter Value by ID, no Run (MC-12)
40
MC-12 Get Unit Configuration (MC-12)
40
MC-12 Send IR Command (MC-12)
43
MC-12 Get Parameter Value by ID (MC-12)
43
MC-12 Set Parameter Notification by ID (MC-12)
44
MC-12 Parameter Get Value String by ID (MC-12)
45
MC-12 Clear All Parameter Notifications (MC-12)
46
MC-12 Get System Status (MC-12)
46
MC-12 Get Record Status (MC-12)
48
MC-12 Set System Volume (MC-12)
49
MC-12 Set Main Balance (MC-12)
49
MC-12 Set Front/Back Balance (MC-12)
50
MC-12 Set Active Effect by ID (MC-12)
50
MC-12 Set Record Input (MC-12)
51
MC-12 Set Zone2 Volume (MC-12)
52
MC-12 Set Zone2 Left/Right Balance (MC-12)
52
MC-12 Get Input Name by ID (MC-12)
53
MC-12 Set Input Name by ID (MC-12)
54
Appendix A Command Codes
55
Appendix B Error Codes
57
Appendix C DC-2, MC-1 IR-Codes
58
Appendix D MC-12 IR Codes
59
Appendix E MC-1 Input ID's
60
Appendix F MC-12 Input Ids
60
Appendix G Protocol Constants
61
Appendix H MC-12 to MC-1 Effect Map
62
Appendix I MC-1 to MC-12 Effect ID Map
63
Appendix J MC-12 Mode Ids
64
Application Notes and Examples
65
Box Initializations
65
MC-12
65
Host
65
Getting System Wide Status and Setup
65
Downloading the System Setup to the
65
Simple System Control & System Status
65
Examples
67
MC-12 Get Unit Configuration
67
Send MC-1 IR Command Example
68
Send MC-12 IR Command Example
69
