Lexmark C510 Service Manual

Diagnostic information 2-39
5021-0XX
906—Magenta toner retract solenoid service check
Step Questions / actions Yes No
1 Turn printer off and remove
I/O board shield. See “I/O
board removal” on
page 4-70 for steps to
remove I/O board shield.
Disconnect DCN4
connector from I/O board.
Measure resistance
between cable pins 5 and
6. Is resistance between
162 and 198 ohms?
Replace I/O
board. See “I/O
board removal”
on page 4-70.
Go to step 5.
Go to step 2.
2 Remove items to expose
toner retract solenoid. See
“Toner retract solenoid
and cam removal” on
page 4-64 for steps. Check
toner retract solenoid cable
connection. Is cable
properly connected?
Go to step 3. Properly connect
cable.
Reassemble and
retest printer.
3 Check toner retract
solenoid cable and
connecting cable for visible
damage. Is either cable
damaged?
Replace
damaged cable
or toner retract
solenoid. See
“Toner retract
solenoid and
cam removal”
on page 4-64.
Reassemble and
retest printer.
Go to step 4.
4 Disconnect toner retract
solenoid cable from cable
that attaches to I/O board.
Check cable continuity from
DCN4 pins 5 and 6 to
connector that attaches to
toner retract solenoid.
Ensure that pins are not
shorted. Is cable okay?
Replace toner
retract solenoid.
See “Toner
retract solenoid
and cam
removal” on
page 4-64.
Reassemble and
retest printer.
Replace cable.
Reassemble and
retest printer.

Lexmark C510 Specifications

General

Certification	FCC Class B, UL 60950 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, Blue Angel, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, C-tick mark Class B, CCC Class B
Product color	White
Built-in display	-
Color	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	13 s
Time to first page (color, normal)	19 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Print speed (color, normal quality, A4/US Letter)	8 ppm
Maximum internal memory	320 MB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Maximum input capacity	780 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Serial (RS-232)
Maximum duty cycle	- pages per month
Page description languages	PCL 6, PDF 1.3, PostScript 3
Package depth	645 mm
Package width	680 mm
Package height	670 mm
Package weight	40600 g
Operating altitude	0 - 2500 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Power consumption (printing)	- W
Ethernet LAN	No

Weight and Dimensions

Depth	420 mm
Width	495 mm
Height	385 mm
