MAINTENANCE
26/40 17200295_002_C0/2016 - © Leybold 270727EI.DOCX
NOTICE
Contamination
Product may get contaminated.
Always wear cleanroom gloves when handling the product.
NOTICE
Inappropriate tools
Sealing surfaces may get damaged.
Do not use sharp-edged tools.
Leybold assumes no liability and the warranty becomes null and void if
maintenance works are performed, which are not covered by this user
manual.
6.1 Exchange of vacuum seals
Figure 6-1
60 Screws 61 Plate seal 62 Bonnet seal
