LG 24MT49S User Manual

ENG
ENGLISH
4
Lifting and moving the TV
Please note the following advice to prevent the TV from being
scratched or damaged and for safe transportation regardless of its
type and size.
y It is recommended to move the TV in the box or packing material
that the TV originally came in.
y Before moving or lifting the TV, disconnect the power cord and
all cables.
y When holding the TV, the screen should face away from you to
avoid damage.
y Hold the top and bottom of the TV frame rmly. Make sure not to
hold the transparent part, speaker, or speaker grill area.
y When transporting the TV, do not expose the TV to jolts or
excessive vibration.
y When transporting the TV, keep the TV upright, never turn the TV
on its side or tilt towards the left or right.
y Do not apply excessive pressure to cause exing /bending of
frame chassis as it may damage screen.
CAUTION
y Avoid touching the screen at all times, as this may result in
damage to the screen.
y When handling the TV, be careful not to damage the protruding
joystick button.
Setting up the TV
CAUTION
y When attaching the stand to the TV set, place the screen facing
down on a cushioned table or at surface to protect the screen
from scratches.
y Do not carry the monitor upside-down by holding the stand
body (or stand base) as this may cause it to fall o, resulting in
damage or injury.
y Do not apply foreign substances (oils, lubricants, etc.) to the
screw parts when assembling the product. (Doing so may
damage the product.)
NOTE
y Lift up the latch at the bottom of the stand base and detach the
stand base from the TV.

LG 24MT49S Specifications

General

3D	No
Color depth	8 bit
Color gamut	72 %
Pixel pitch	0.38175 x 0.38175 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	24 \
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Peak luminance ratio	66 %
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	60 cm
Screen format adjustments	4:3, 16:9
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1366 x 768
Motion interpolation technology	-
TV tuner integrated	Yes
Annual energy consumption	33 kWh
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
RMS rated power	10 W
Number of speakers	2
Product color	Black
Mercury content	0 mg
Panel mounting interface	75 x 75 mm
Video compression formats	DivX
Tuner type	Analog & digital
Number of OSD languages	34
On Screen Display (OSD) languages	ALB, BOS, BUL, CRO, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, KAZ, LAT, LIT, MAC, NOR, POL, POR, RUM, SER, SLK, SLV, SWE, TUR, UKR
HDMI version	1.4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)	SimpLink
AC input voltage	100 - 240 V
Power consumption (standby)	0.4 W
Power consumption (typical)	23 W
Cables included	AC
Package type	Box
Package depth	126 mm
Package width	700 mm
Package height	402 mm
Package weight	4500 g
Quantity per intermodal container (20ft)	704 pc(s)
Quantity per intermodal container (40ft, HC)	1672 pc(s)

Weight and Dimensions

Depth (with stand)	143.4 mm
Height (with stand)	392.7 mm
Weight (with stand)	3500 g
Depth (without stand)	54.7 mm
Width (without stand)	556 mm
Height (without stand)	345.2 mm
Weight (without stand)	3200 g
