LG 24MT49S User Manual

ENGENGLISH
7
Connections (notications)
Connect various external devices to the TV and switch input modes
to select an external device. For more information about an external
device’s connection, refer to the manual supplied with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio
systems, USB storage devices, PC, camcorders or cameras, gaming
devices, and other external devices.
NOTE
y The external device connection may dier from the model.
y Connect external devices to the TV regardless of the order of the
TV port.
y If you record a TV programme on a DVD recorder or VCR, make
sure to connect the TV signal input cable to the TV through a DVD
recorder or VCR. For more information of recording, refer to the
manual provided with the connected device.
y Refer to the external equipment’s manual for operating
instructions.
y If you connect a gaming device to the TV, use the cable supplied
with the gaming device.
y In PC mode, there may be noise associated with the resolution,
vertical pattern, contrast or brightness. If noise is present, change
the PC output to another resolution, change the refresh rate
to another rate or adjust the brightness and contrast on the
PICTURE menu until the picture is clear.
y In PC mode, some resolution settings may not work properly
depending on the graphics card.
Antenna connection
Connect the TV to a wall antenna socket with an RF cable (75 Ω).
y Use a signal splitter to use more than 2 TVs.
y If the image quality is poor, install a signal amplier properly to
improve the image quality.
y If the image quality is poor with an antenna connected, try to
realign the antenna in the correct direction.
y An antenna cable and converter are not supplied.
y Supported DTV Audio: MPEG, Dolby Digital, Dolby Digital Plus,
HE-AAC
Satellite dish connection
(Only satellite models)
Connect the TV to a satellite dish to a satellite socket with a satellite
RF cable (75 Ω).
CI module connection
View the encrypted (pay) services in digital TV mode.
y Check if the CI module is inserted into the PCMCIA card slot in the
right direction. If the module is not inserted properly, this can
cause damage to the TV and the PCMCIA card slot.
y If the TV does not display any video and audio when CI+ CAM is
connected, please contact to the Terrestrial/Cable/Satellite Service
Operator.
PC connection
When connecting your PC to the HDMI input, set the HDMI input’s
Input Label to PC.
(Inputs) (Remote control) All Inputs EDIT ICON
PC
Other connections
Connect your TV to external devices. For the best picture and audio
quality, connect the external device and the TV with the HDMI cable.
Some separate cable is not provided.
y Supported HDMI Audio format:
Dolby Digital / Dolby Digital Plus (32 kHz, 44.1 kHz, 48 kHz),
DTS (44.1 kHz, 48 kHz),
PCM (32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz)
(Depending on model)

LG 24MT49S Specifications

General

3D	No
Color depth	8 bit
Color gamut	72 %
Pixel pitch	0.38175 x 0.38175 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	24 \
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Peak luminance ratio	66 %
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	60 cm
Screen format adjustments	4:3, 16:9
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	200 cd/m²
Supported graphics resolutions	1366 x 768
Motion interpolation technology	-
TV tuner integrated	Yes
Annual energy consumption	33 kWh
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
RMS rated power	10 W
Number of speakers	2
Product color	Black
Mercury content	0 mg
Panel mounting interface	75 x 75 mm
Video compression formats	DivX
Tuner type	Analog & digital
Number of OSD languages	34
On Screen Display (OSD) languages	ALB, BOS, BUL, CRO, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, KAZ, LAT, LIT, MAC, NOR, POL, POR, RUM, SER, SLK, SLV, SWE, TUR, UKR
HDMI version	1.4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)	SimpLink
AC input voltage	100 - 240 V
Power consumption (standby)	0.4 W
Power consumption (typical)	23 W
Cables included	AC
Package type	Box
Package depth	126 mm
Package width	700 mm
Package height	402 mm
Package weight	4500 g
Quantity per intermodal container (20ft)	704 pc(s)
Quantity per intermodal container (40ft, HC)	1672 pc(s)

Weight and Dimensions

Depth (with stand)	143.4 mm
Height (with stand)	392.7 mm
Weight (with stand)	3500 g
Depth (without stand)	54.7 mm
Width (without stand)	556 mm
Height (without stand)	345.2 mm
Weight (without stand)	3200 g
