- 15 -
LGE Internal Use OnlyCopyright ©2011 LG Electronics. Inc. All rights reserved.
Only for training and service purposes
BLOCK DIAGRAM
NAND
Flash ( 8Gb)
Audio
AMP
PCMCIA
Tuner_CVBS
USB
COM P1
A/V1
SCART
RS-232C
PC- RGB
PC- AUDI O
SPDI F
SYSTEM
DDR3 X 16 X 2
(2Gb)
51P
HDMI 1
HDMI 2
HDMI 3
H/ P
SYSTEM EEPROM X 1
(1Mb)
TUNER
(T/ C)
41P
SPI
Flash ( 2M b )
SYSTEM
DDR3 X 16 X 1
(1Gb)
Tuner_SI F
SCL/ SDA
CI_TS_DATA[7:0]/CLK/Valid/Sync
CI _DATA[ 7:0]
CI _ ADDR[ 14 : 0 ]
FE_TS_DATA[0]/CLK/Valid/Sync
USB_DM/ DP
HP_OUT
DSUB_RGB/ HVsync
DDC_SDA/ UART_TX
PC_ Au d i o I N
SPDI F_OUT
Debug _TX/ RX
SC_CVBS/ RGB/ LR_ I N
SC_VI DEO/ LR_OUT
AV_CVBS/ LR_I N
COMP_ YPb Pr / LR_ I N
HDMI _TMDS/ HPD/ CEC
HDMI _TMDS/ HPD/ CEC
HDMI _TMDS/ HPD/ CEC
I2S_I/F
SCL/ SDA
30P
Side
Rear
DATA
Video
Audio
DATA
Video
Audio
Su b Mi com
(NEC)
HDCP EEPROM X 1
(8Kb)
For FRC
SPI
Flash ( 8M b )
SCL/ SDA
SCL/ SDA
LGE101 (S7R)
LGE107 (S7+URSA)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG 32LK330U and is the answer not in the manual?

LG 32LK330U Specifications

General IconGeneral
Product colorBlack
LED indicatorsY, Stand-by
3DNo
Annual energy consumption132 kWh
Display diagonal32 \
Display brightness350 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Supported video modes1080i, 1080p, 720p
Contrast ratio (dynamic)70000:1
Display diagonal (metric)80 cm
Supported graphics resolutions1366 x 768
CertificationRoHs
Audio formats supportedMP3
Image formats supportedJPG
Video formats supportedDIVX, MPEG4
Audio (L/R) in0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out1
Power consumption (standby)0.3 W
Power consumption (typical)91 W
RMS rated power20 W
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)206.8 mm
Width (with stand)800 mm
Height (with stand)565 mm
Weight (with stand)9200 g
Depth (without stand)73.8 mm
Height (without stand)509 mm
Weight (without stand)8200 g
