11
ATTACHING THE TV TO A WALL
PREPARATION
■
Set it up close to the wall so the set doesn’t fall over when it is pushed backwards.
■
The instructions shown below is a safer way to set up the set, which is to fix it on the wall so the set doesn’t
fall over when it is pulled in the forward direction. It will prevent the set from falling for-ward and hurting
people. It will also prevent the set from damage caused by fall. Please make sure that children don’t climb
on or hang from the set.
Use a sturdy rope (not provided as parts of the set,
must purchase separately) to tie the set. It is safer
to tie the rope so it becomes horizontal between
the wall and the set.
Use the set brackets/bolts to fix the set to the wall
as shown in the picture.
(If your set has the bolts in set brackets/bolts posi-
tion before inserting the set brackets/bolts, loosen
the bolts.)
* Insert the set brackets/bolts and tighten them
securely in the upper holes.
Secure the wall brackets with the bolts (not provid-
ed as parts of the set, must purchase separately) on
the wall. Match the height of the bracket that is
mounted on the wall.
NOTE
GG
When moving the set to another place undo the ropes first.
GG
Use a set holder or a cabinet that is big and strong enough for the size and weight of the set.
GG
To use the set safely make sure that the height of the bracket that is mounted on the wall is same as that
of the set.
1
3
2
2
3
1
USE POWER CORD HOLDER
After connecting the power cord to the AC input
terminal, remove the bolt at the hole on the back
cover and fix the power cord at the rear side of the
TV by using the bracket for fixing the power cord.
* This feature is not available for all models.
