LG 32WFC User Manual

ENGLISH
23
LVDS PIN MAP GUIDE
• LCD Connector (CN1) : FI-RE51S-HF or Equivalent, refer to below table.
• Mating Connector : FI-RE51HL
• Cable length: 1 m of coaxial cable or less
Pin No. Symbol Description Note
1 NC or GND No Connection or Ground
2 NC No Connection 4
3 NC No Connection 4
4 NC No Connection 4
5 NC No Connection 4
6 NC No Connection 4
7 LVDS Select 'H' = JEIDA, 'L' = VESA
8 NC No Connection
9 NC No Connection
10 NC No Connection
11 GND Ground 1
12 R1AN FIRST LVDS Receiver Signal(A-)
13 R1AP FIRST LVDS Receiver Signal(A+)
14 R1BN FIRST LVDS Receiver Signal(B-)
15 R1BP FIRST LVDS Receiver Signal(B+)
16 R1CN FIRST LVDS Receiver Signal(C-)
17 R1CP FIRST LVDS Receiver Signal(C+)
18 GND Ground 1
19 R1CLKN FIRST LVDS Receiver Clock Signal(-)
20 R1CLKP FIRST LVDS Receiver Clock Signal(+)
21 GND Ground 1
22 R1DN FIRST LVDS Receiver Signal(D-)
23 R1DP FIRST LVDS Receiver Signal(D+)
24 NC No Connection 4
25 NC No Connection 4
26 NC or GND No Connection or Ground
27 NC No Connection 4
28 R2AN SECOND LVDS Receiver Signal(A-)
29 R2AP SECOND LVDS Receiver Signal(A+)
30 R2BN SECOND LVDS Receiver Signal(B-)
31 R2BP SECOND LVDS Receiver Signal(B+)
32 R2CN SECOND LVDS Receiver Signal(C-)
33 R2CP SECOND LVDS Receiver Signal(C+)
34 GND Ground 1
35 R2CLKN SECOND LVDS Receiver Clock Signal(-)
36 R2CLKP SECOND LVDS Receiver Clock Signal(+)
37 GND Ground 1
