EXTERNAL EQUIPMENT SETUP
33
AUDIO OUT SETUP
Send the TV’s audio to external audio equipment via the Digital Audio Output
(
Optical
)
port.
GG
When connecting with external audio equipments, such as ampli-
fiers or speakers, please turn the TV speakers off. (
GG
pp..6699
)
NOTE
!
GG
Do not look into the optical output port. Looking at the
laser beam may damage your vision.
GG
Block the SPDIF out(optical/coaxial) about the contents
with ACP(Audio Copy Protection) function.
CAUTION
Connect one end of the optical or coaxial cable to the TV’s
OOPPTTIICCAALL
or
CCOOAAXXIIAALL
port of
DDIIGGIITTAALL AAUUDDIIOO OOUUTT
.
Connect the other end of the optical or coaxial cable to the
digital audio input on the audio equipment.
Set the “TV Speaker option - Off” in the AUDIO menu. (
GG
pp..6699
). See the external audio equipment instruction manual
for operation.
1. How to connect
2
3
1
Connect audio outputs to the TV’s
AAUUDDIIOO OOUUTT
jacks.
Set the “TV Speaker option - Off” in the AUDIO menu.
(
GG
pp..6699
). See the external audio equipment instruction
manual for operation.
1. How to connect
2
1
Analog
Digital
AV IN 1
REMOTE
CONTROL IN
ANTENNA/
CABLE IN
RS-232C IN
(CONTROL & SERVICE)
OPTICAL COAXIAL
VIDEO
MONO
( )
AUDIO
S-VIDEO
AUDIO OUT
( )
DIGITAL AUDIO OUT
L R
AUDIO
1
( )
IN
AV IN 1
DIO
DVI)
REMOTE
CONTROL IN
ANTENNA/
CABLE IN
RS-232C IN
(CONTROL & SERVICE)
AUDIO
AUDIO OUT
VIDEO
MONO
( )
AUDIO
S-VIDEO
DIGITAL AUDIO OUT
OPTICAL
COAXIAL
1
2
