EXPLODED VIEW PARTS LIST

Loc. No. PART NO. QISDA PART NO. DESCRIPTION

120 COV30059901 2C.40GK0.001 OEM Qisda 2C.40GK0.001 SPEAKER Z37LC6D-UM

200 COV30057201 5F.MUMV0.031 OEM Qisda AUO MODULE T370XW02-VC Z37LC6D-UM

300 ABJ56904904 6K.0GL02.041 Cabinet Assembly 37LC6D LA75C 37” Qisda OS LG LOGO

400 ACQ56905403 6K.0GL03.012 Cover Assembly,Rear Z37LC6D LA75C 37” Qisda V0, B/C ASSY

500 EBR57525401 5E.0GK03.001 PCB Assembly,Sub SUB T.T IR ASSY Z32LC6D-UM QISDA ODM

501 MES49416701 4B.0GK01.001 Indicator MOLD PMMA PRE AMP Z32LC6D

502 MES49417001 4B.0GK02.001 Indicator MOLD PMMA POWER Z32LC6 POWER INDICATOR

510 EBR57525601 5E.0GL02.001 PCB Assembly,Sub SUB T.T KEY ASSY Z37LC6D-UM QISDA ODM

511 ABA56902102 6K.0GK05.011 Bracket Assembly CONTROL Z32LC6D LA75C CONTROL BUTTON ASSY

520 EBR57525201 5E.0GK38.001 PCB Assembly,Sub SUB T.T SIDE A/V QISDA ODM ALL

521 ABA56905501 6K.0GL06.001 Bracket Assembly SIDE AV Z37LC6D LA75C SIDE AV ASSY, Z37LC6D

530 COV30057301 5D.0GK07.011 OEM Qisda PSU Z37LC6D-UM

540 EBU57524901 5E.0GL01.001 Main Total Assembly Z37LC6D-UM ZENITH Qisda ODM MAIN ASSY

550 COV30059701 5K.0GL09.011 OEM Qisda AC socket Z37LC6D-UM

551 MJH49414801 3D.0GK02.001 Supporter PRESS EGI 1.2T Supporter SECC(EGI) AC HOLDER

801 MGJ49418002 3K.0GL01.001 Plate,Metal PRESS SECC 1.2T FRAME SECC METAL BAR TOP

802 MGJ49418902 3K.0GL02.001 Plate,Metal PRESS SECC 1.2T FRAME SECC METAL BAR BOTTOM

803 MGJ49418201 3K.0GL03.001 Plate,Metal PRESS SECC 1.2T FRAME SECC METAL BAR RIGHT

804 AGU56906001 6K.0GL08.001

Plate Assembly SUPPORTER LEFT, METAL BAR ASSY INCLUDING FIBER

805 MGJ49418101 3K.0GL05.001 Plate,Metal PRESS SECC 1.2T FRAME METAL BAR VERTICAL MIDDLE

806 AGU56906102 6K.0GL09.002 Plate Assembly SUPPORTER METAL BAR H TOP + FIBER

807 AGU56906302 6K.0GL10.002 Plate Assembly SUPPORTER METAL BAR H BOTTOM + FIBER

808 MJH49418601 3K.0GL06.001 Supporter PRESS SECC 1.2T Supporter SECC(EGI) STAND SUPPORTER

820 MGJ57813001 6K.0GM13.001 Plate,Shield PRESS EGI - SHIELD EGI TOP SHIELD

821 MGJ57813601 6K.0GM14.002 Plate,Shield PRESS EGI - SHIELD EGI SHIELD BOTTOM

830 AAN56905602 6K.0GL11.012 Base Assembly STAND Z37LC6D LA75C Qisda BRACKET, Z37LC6D

900 AAN56905102 6K.0GL04.002 Base Assembly STAND Z37LC6D LA75C STAND BASE ASSY
