EXTERNAL EQUIPMENT SETUP
42
EXTERNAL EQUIPMENT SETUP
HD RECEIVER SETUP
Component Connection
1. How to connect
2
1
2. How to use
Connect the video outputs
(
Y, PB, PR
)
of the digital set-
top box to the
CCOOMMPPOONNEENNTT IINN VVIIDDEEOO
* or
CCOOMM--
PPOONNEENNTT IINN VVIIDDEEOO 11
*/
22
* jacks on the TV. Match
the jack colors (Y = green, P
B = blue, and PR = red).
Connect the audio output of the digital set-top box to the
CCOOMMPPOONNEENNTT IINN AAUUDDIIOO
* or
CCOOMMPPOONNEENNTT IINN
AAUUDDIIOO 11
*/
22
* jacks on the TV.
■
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box operation.
)
■
Select the
CCoommppoonneenntt
*or
CCoommppoonneenntt11
*/
22
* input
source on the TV using the
IINNPPUUTT
button on the remote
control.
■
To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.
■
This part of EXTERNAL EQUIPMENT SETUP mainly use picture for
2266//3322//3377//4422LLHH2200RR
.
L(MONO
VIDEO
1
2
HDMI
/DVI IN
HDMI
RS-232C IN
(CONTROL)
RGB IN (PC)
USB IN
SERVICE ONLY
AUDIO IN
(RGB/DVI
AV
AUDIOAUDIO
VIDEOVIDEO
VARIABLE A
Y L RP B P R
COMPONENT IN
1
2
*
CCOOMMPPOONNEENNTT IINN VVIIDDEEOO
/
AAUUDDIIOO
: For 19/22/26/32/37/42LH20R, 32/42LF20FR,
32/37/42/47LH30FR, 19LU50R, 22/26LU50FR,
22LU40R, 22/26/32LD330, 32/42LD410, 32/42LD420,
32LD340, 26/32LD331C
*
CCOOMMPPOONNEENNTT IINN VVIIDDEEOO 11//22,, AAUUDDIIOO 11//22
,
: For 42/47/55LH50YR, 32/42/47LH70YR,
42/47LH90QR, 32/42/47/55SL80YR, 42/47SL90QR
*
CCoommppoonneenntt
: For 19/22/26/32/37/42LH20R, 32/42LF20FR,
32/37/42/47LH30FR, 19LU50R, 22/26LU50FR,
22LU40R, 22/26/32LD330, 32/42LD410,
32/42LD420, 32LD340, 26/32LD331C
*
CCoommppoonneenntt11
/
22
: For 42/47/55LH50YR, 32/42/47LH70YR,
42/47LH90QR, 32/42/47/55SL80YR,
42/47SL90QR
Supported Resolutions
Signal
480i
480p
720p
108 0 i
108 0 p
Component
Yes
Yes
Yes
Yes
Yes (50/60Hz only)
HDMI
No
Yes
Yes
Yes
Yes (24/30/50/60Hz)
Y, C
B/
PB, CR/PR
Horizontal Vertical
Frequency
(
KHz
)
Frequency
(
Hz
)
15 . 73 59 . 9 4
15.75 60.00
31 . 47 59 . 9 4
31.50 60.00
15.625 50.00
31.25 50.00
44.96 59.94
45.00 60.00
37.50 50.00
28.125 50.00
33.72 59.94
33.75 60.00
56.25 50.00
67.432 59.94
67.50 60.00
Resolution
720x480i
720x480p
1280x720p
1920x1080i
1920x1080p
720x576i
720x576p
MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 42

LG 37LH20R Specifications

General

Display diagonal	37 \
Progressive scan	No
Display brightness	500 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Supported video modes	1080p
Contrast ratio (dynamic)	60000:1
Screen format adjustments	4:3, 14:9
Supported graphics resolutions	1920 x 1080 (HD 1080)
RS-232 ports	1
PC in (D-Sub)	Yes
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	180 W
Product color	Black
RMS rated power	10 W
Number of speakers	2
Tuner type	Analog
Analog signal format system	PAL, PAL BG, PAL DK, PAL I, PAL N, SECAM, SECAM B/G, SECAM D/K
