LG 42LH260H User Manual

EXTERNAL EQUIPMENT SETUP
27
PC SETUP
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
VGA (D-Sub 15 pin) Connection
O
O
R
R
RGB OUTPUT
AUDIO
2
1
/DVI IN
AUDIO IN
RGB IN (PC)
UPDATE
RESET
(RGB/DVI)
RS-232C IN
( SERVICE ONLY)
REMOTE
CONTROL OUT
SPEAKER OUT
(8 )
1
2
2. How to use
■
Turn on the PC and the TV.
■
Select the
RRGGBB--PPCC
input source on the TV using the
IINNPPUUTT
button on the remote control.
Connect the VGA output of the PC to the
RRGGBB IINN
((
PP CC
))
jack on the TV.
Connect the PC audio output to the
AAUUDDIIOO IINN
((
RRGGBB//DDVVII
))
jack on the TV.
1. How to connect
2
1
DVI to HDMI Connection
VIDEO
AUDIO
VIDEO AUDIO
L(MONO) R
AV IN 1
COMPONENT IN
L R
AUDIO
DVI OUTPUT
2
1
/DVI IN
AUDIO IN
UPDATE
RESET
(RGB/DVI)
RS-232C IN
( SERVICE ONLY)
SPEAKER OUT
RGB IN (PC)
REMOTE
CONTROL OUT
(8 )
1
2
2. How to use
■
Turn on the PC and the TV.
■
Select the
HHDDMMII11
input source on the TV using the
IINNPPUUTT
button on the remote control.
Connect the DVI output of the PC to the
HHDDMMII//DDVVII IINN
11
jack on the TV.
Connect the PC audio output to the
AAUUDDIIOO IINN
((RRGGBB//DDVVII))
jack on the TV.
1. How to connect
2
1

LG 42LH260H Specifications

General

Equalizer	Yes
Audio system	SRS TruSurround XT
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
Equalizer bands quantity	5
Product color	Black
Panel mounting interface	200 x 200 mm
Comb filter	3D
Display diagonal	42 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Supported video modes	1080p
Contrast ratio (dynamic)	20000:1
Supported graphics resolutions	1920 x 1080 (HD 1080)
Package depth	228.6 mm
Package width	1330.95 mm
Package height	769.62 mm
Package weight	21180 g
Audio formats supported	MP3
Image formats supported	JPG
Video formats supported	H.264, MPEG2, MPEG4
Placement supported	Horizontal
Mean time between failures (MTBF)	50000 h
Certification	RoHS
HDMI version	1.3
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC

Weight and Dimensions

Depth (with stand)	294.64 mm
Width (with stand)	1026.15 mm
Height (with stand)	713.74 mm
Weight (with stand)	18600 g
Depth (without stand)	86.36 mm
Height (without stand)	652.78 mm
Weight (without stand)	16780 g
