July 2009 LCD DV 42LH40
56
FRONT CONTROL BOARD CONNECTIONS IDENTIFIED
FRONT CONTROL BOARD CONNECTIONS IDENTIFIED
The below picture shows the connections to the Front Control board.
Side
Key
P3000
P2
P1
Main Power
Switch
p/n EBR59216901
