Side Key Assembly P3000 Voltage and Diode Check
Side Key Assembly P3000 Voltage and Diode Check
P3000 Resistance Measurements with Key pressed.
CH (Up)
CH (Dn)
Volume (+)
Volume (-)
KEY
10K Ohms
4.8K Ohms
1.8K Ohms
270.5 Ohms
Pin 3 measured
from Gnd
10K Ohms
4.8K Ohms
1.8K Ohms
270.5 Ohms
Pin 1 measured
from Gnd
Enter
Menu
Input
Power
KEY
P3000 Voltage Measurements with Key pressed.
CH (Up)
CH (Dn)
Volume (+)
Volume (-)
KEY
2.24V
1.65V
0.906V
0.179V
Pin 3 measured
from Gnd
2.24V
1.65V
0.906V
0.179V
Pin 1 measured
from Gnd
Enter
Menu
Input
Power
KEY
P3000 Connector “Side Key" to “IR/LED Control PWB“ P1
Gnd
Key2
Gnd
Key1
Label
Gnd
Open
Gnd
Open
Diode Check
GndGnd4
3.3V3.3V3
GndGnd2
3.3V3.3V1
Run STBYPin
c
P3000
