ENGLISH
18
MAKING CONNECTIONS
Connecting to a HD receiver, DVD player, or VCR
Connect a HD receiver, DVD player, or VCR to the TV and select an appropriate input mode.
HDMI connection
HDMI is the best way to connect a device.
Transmits digital video and audio signals from an external device to the TV. Connect the external device
and the TV with the HDMI cable as shown in the following illustration.
Use the latest High Speed HDMI™ Cable that supports CEC (Customer Electronics Control)
function.
High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
HDMI Audio Supported Format: Dolby Digital, PCM (Up to 192 kHz, 32 kHz / 44.1 kHz / 48 kHz /
96 kHz / 192 kHz) -> DTS is not supported.
NOTE
Choose any HDMI input port to connect.
It does not matter which port you use.
IN 2 (MHL)
HDMI
IN
1
(*Not provided)
DVD / Blu-Ray / HD Cable Box / HD STB
To Next Page
