26
ENG
ENGLISH
MAKING CONNECTIONS
HDMI connection
Transmits the digital video and audio signals from
an external device to the TV. Connect the external
device and the TV with the HDMI cable as shown.
HDMI
IN
DVD/ Blu-Ray /
HD Cable Box
/ HD STB
(*Not Provided)
NOTE
It is recommended to use the TV with the
HDMI connection for the best image quality.
High Speed HDMI™ Cables are tested to
carry an HD signal up to 1080p and higher.
Supported HDMI Audio format : PCM
(32k/44.1k/48k, DTS Not supported.)
Adapter connection
(Only 19/22/26LS33**)
DC IN
DC Adapter
1 Connect the antenna cable to the antenna
input port on the TV.
2 Connect the DC adapter plug to the power
input jack on the TV.
3 Connect the power cord to the DC adapter rst,
then plug the power cord into the wall power
outlet.
CAUTION
Please be sure to connect the TV to the DC
power adapter before connecting the TV’s
power plug to a wall power outlet.
To Next Page
