Connecting the Speakers
- For certain models only. (Only for **SE3B/**SL5B
model)
- The image may be different according to the
model.
1 Connect an input signal cable before installing
the speakers.
1 Connect an input signal cable before installing
the speakers.
3 Then connect the speaker cable. After installing
your speakers, use holders and cable ties to
organize the speaker cables.
3 Then connect the speaker cable. After installing
your speakers, use holders and cable ties to
organize the speaker cables.
2 Mount the speakers by using screws as
shown below. Make sure the power cable is
disconnected before making a connection.
2 Mount the speakers by using screws as
shown below. Make sure the power cable is
disconnected before making a connection.
32SE3B
43/49/55/65SE3B 43/49/55SL5B
