LG 49SE3KB User Manual

50
CUSTOMIZING SETTINGS
ENGLISH
OPTION Settings
1
Press SETTINGS to access the main menus.
2
Press the navigation buttons to scroll to OPTION and press OK.
3
Press the navigation buttons to scroll to the setting or option you want and press OK.
- To return to the previous level, press BACK.
4
When you are finished, press EXIT.
When you return to the previous menu, press BACK.
The available option settings are described in the following:
Setting Description
Language Selects a language for the display text.
Country Select your country.
DivX(R) VOD Registers or releases DivX.
Checks DivX Registration Code for playing DivX-protected videos.
Register at http://vod.divx.com .
Uses Registration Code to rent or purchase movies at www.divx.com/vod .
* Rented/purchased DivX files cannot be played if the DivX Registration Code of a
different device is used. Use only the DivX Registration Code granted to this device.
* Converted files not conforming to the DivX Codec Standard may not play or may
produce abnormal images.
Initial Setting Deletes all optional settings and returns to initial default mode.
Set ID You can assign a unique Set ID NO (name assignment) to each product when several
products are connected for display. Specify the number (1 to 255 or 1 to 1,000) using the
button and exit. Use the assigned Set ID to individually control each product using the
Product Control Program.
Tile Mode Tile Mode To use this function
- Must be displayed with various other products.
- Select Tile Mode, set rows and columns, and then enter the tile ID to
set the location.
- Tile Mode: row x column (row = 1-15, column = 1-15).
- 15 x 15 available.
Auto Config. Sets to adjust the screen position, clock, and phase automatically.
The displayed image may be unstable for a few seconds while the
configuration is in progress.
Position Moving the screen position horizontally and vertically.
Size Adjust the horizontal and vertical size of the screen taking into
account the size of the bezel.
Natural The image is omitted by the distance between the screens to be
naturally shown.
Reset Function to initialize and release Tile.
All Tile setting are released when selecting Tile recall and the screen
returns to Full screen.

LG 49SE3KB Specifications

General

Response time	12 ms
Display diagonal	49 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Supported video modes	720p, 1080i, 1080p
Contrast ratio (dynamic)	500000:1
Contrast ratio (typical)	1100:1
Display diagonal (metric)	124.46 cm
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	11.9 mm
Bezel width (bottom)	18 mm
Panel mounting interface	300 x 300 mm
Smart modes	Energy saving
Multi-display supported	-
USB ports quantity	2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	20 W
Sound modes	Music, Sports, News, Standard, Movie, Game
Audio system	Clear Voice II, Virtual Surround Plus
Bundled software	SuperSign-w lite SuperSign-c
Package depth	134 mm
Package width	1197 mm
Package height	760 mm
Package weight	17100 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (typical)	70 W
Sustainability certificates	ENERGY STAR
Certification	UL / cUL / CB / TUV / KC FCC Class \
Cables included	VGA, AC

Weight and Dimensions

Depth	38.6 mm
Width	1102.2 mm
Height	638.5 mm
Weight	14100 g
