TO CONTROL MULTIPLE PRODUCTS
ENGLISH
TO CONTROL MULTIPLE PRODUCTS
►y Use this method to connect several products to a single PC. You can control several products at a time by connecting
them to a single PC.
►y In the Option menu, Set ID must be between 1 and 255 (or from 1 to 1,000) without being duplicated.
Connecting the Cable
Connect the RS-232C cable as shown in the picture.
►y The RS-232C protocol is used for communication between the PC and product. You can turn the product on or off,
select an input source or adjust the OSD menu from your PC.
Monitor 1 Monitor 2 Monitor 3Monitor 4
PC
RS-232C
IN
RS-232C
OUT
RS-232C
IN
RS-232C
OUT
RS-232C
IN
RS-232C
OUT
RS-232C
IN
RS-232C
OUT
RS-232C Gender
4P Cable
(not included)
RS-232C Cable
(not included)

LG 49SE3KB Specifications

General

Response time	12 ms
Display diagonal	49 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Supported video modes	720p, 1080i, 1080p
Contrast ratio (dynamic)	500000:1
Contrast ratio (typical)	1100:1
Display diagonal (metric)	124.46 cm
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	11.9 mm
Bezel width (bottom)	18 mm
Panel mounting interface	300 x 300 mm
Smart modes	Energy saving
Multi-display supported	-
USB ports quantity	2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	20 W
Sound modes	Music, Sports, News, Standard, Movie, Game
Audio system	Clear Voice II, Virtual Surround Plus
Bundled software	SuperSign-w lite SuperSign-c
Package depth	134 mm
Package width	1197 mm
Package height	760 mm
Package weight	17100 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (typical)	70 W
Sustainability certificates	ENERGY STAR
Certification	UL / cUL / CB / TUV / KC FCC Class \
Cables included	VGA, AC

Weight and Dimensions

Depth	38.6 mm
Width	1102.2 mm
Height	638.5 mm
Weight	14100 g
