LG 49SE3KB User Manual

15
ASSEMBLY AND PREPARATION
ENGLISH
Portrait Layout
When installing in a portrait layout, rotate the
monitor counterclockwise 90 degrees (when facing
the screen).
(This is not available for all models.)
The Kensington security system connector is
located at the back of the monitor. For more
information on installation and use of this system,
refer to the manual provided with the Kensington
security system or visit http://www.kensington.
com .
Connect the Kensington security system cable
between the monitor and a table.
Using Kensington Lock
• The Kensington security system is optional. You
can obtain additional accessories from most
electronics retail stores.
NOTE

LG 49SE3KB Specifications

General

Response time	12 ms
Display diagonal	49 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Supported video modes	720p, 1080i, 1080p
Contrast ratio (dynamic)	500000:1
Contrast ratio (typical)	1100:1
Display diagonal (metric)	124.46 cm
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	11.9 mm
Bezel width (bottom)	18 mm
Panel mounting interface	300 x 300 mm
Smart modes	Energy saving
Multi-display supported	-
USB ports quantity	2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	20 W
Sound modes	Music, Sports, News, Standard, Movie, Game
Audio system	Clear Voice II, Virtual Surround Plus
Bundled software	SuperSign-w lite SuperSign-c
Package depth	134 mm
Package width	1197 mm
Package height	760 mm
Package weight	17100 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (typical)	70 W
Sustainability certificates	ENERGY STAR
Certification	UL / cUL / CB / TUV / KC FCC Class \
Cables included	VGA, AC

Weight and Dimensions

Depth	38.6 mm
Width	1102.2 mm
Height	638.5 mm
Weight	14100 g
