LG 49UK6300PUE User Manual

Normal
audio
Y
N
Move to No
video/No audio
No video
Normal audio
Check Back Light
On with naked eye
On
Y
N
Check Power
Board
13.2V etc.
Normal
voltage
Y
N
Replace T-con/Main
Board or module
Repair Power
Board or parts
Check Power Board 13.2V output
Normal
voltage
Y
Replace Inverter
or module
N
Repair Power
Board or parts
End
Always check & record S/W Version and White
Balance value before replacing the Main Board
Replace Main Board
Re-enter White Balance value
※Precaution
Established
date
Standard Repair Process
Revised date
1/16
Error
symptom
A. Video error
No video/ Normal audio
☞A18 ☞A1
☞A18
☞A4 & A2
First of all, Check whether all of cables between board is inserted properly or not.
(Main B/D↔ Power B/D, LVDS or EPI Cable, Speaker Cable, IR B/D Cable,,,)
1
Copyright © 2018 LG Electronics Inc. All rights reserved.
Only for training and service purposes.

LG 49UK6300PUE Specifications

General

Sustainability certificates	ENERGY STAR
Cables included	AC
3D	No
App store	LG Content Store
Annual energy consumption	123 kWh
Screen shape	Flat
Response time	- ms
Display diagonal	49 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
Supported video modes	2160p
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	TruMotion 120 Hz
Tuner type	Digital
Analog signal format system	-
Digital signal format system	ATSC
Video apps	Netflix, YouTube
Lifestyle apps	Google Apps
Operating system version	4.0
Operating system installed	Web OS
Audio decoders	DTS, DTS-HD
RMS rated power	20 W
Number of speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Product color	Black, Grey
Panel mounting interface	300 x 300 mm
Processor cores	4
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	SimpLink
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W

Weight and Dimensions

Depth (with stand)	231 mm
Height (with stand)	709 mm
Weight (with stand)	11300 g
Depth (without stand)	81 mm
Width (without stand)	1110 mm
Height (without stand)	650 mm
Weight (without stand)	11100 g
