Standard Repair Process Detail Technical Manual
Revised
date
A1
Error
symptom
Content
CHECK the vby1 LED and Module supply voltage
A. Video error_No video/Normal audio
LCD TV
A1
‘Red LED signal ‘ means video output is good
(Vx1 signal is locked)
Check the Module supply voltage ’24V’
Copyright © 2015 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only
