- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5. Video resolutions
5.1. Component 2D Input (Y, CB/PB, CR/PR)
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Proposed
1
720*480 15.73 60 13.5135 SDTV ,DVD 480I
2
720*480 15.73 59.94 13.5 SDTV ,DVD 480I
3 720*480 31.50 60 27.027 SDTV 480P
4 720*480 31.47 59.94 27.0 SDTV 480P
5 1280*720 45.00 60.00 74.25 HDTV 720P
6 1280*720 44.96 59.94 74.176 HDTV 720P
7 1920*1080 33.75 60.00 74.25 HDTV 1080I
8 1920*1080 33.72 59.94 74.176 HDTV 1080I
9 1920*1080 67.50 60.00 148.50 HDTV 1080P
10 1920*1080 67.432 59.94 148.352 HDTV 1080P
5.2. Component 3D Input (Y, CB/PB, CR/PR)
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) 3D input proposed mode Proposed
1
1280*720 45.00 60.00 74.25 2D to 3D,Side by Side, Top and Bottom HDTV 720P
2
1280*720 44.96 59.94 74.176 2D to 3D,Side by Side, Top and Bottom HDTV 720P
3 1920*1080 33.75 60.00 74.25 2D to 3D,Side by Side, Top and Bottom HDTV 1080I
4 1920*1080 33.72 59.94 74.176 2D to 3D,Side by Side, Top and Bottom HDTV 1080I
5 1920*1080 67.5 60 2D to 3D,Side by Side, Top and Bottom HDTV 1080p
6 1920*1080 67.432 59.94 2D to 3D,Side by Side, Top and Bottom HDTV 1080p
7 1920*1080 27 24 2D to 3D,Side by Side, Top and Bottom HDTV 1080p
8 1920*1080 28.12 25 2D to 3D,Side by Side, Top and Bottom HDTV 1080p
9 1920*1080 26.97 23.976 2D to 3D,Side by Side, Top and Bottom HDTV 1080p
10 1920*1080 33.75 30 2D to 3D,Side by Side, Top and Bottom HDTV 1080p
11 1920*1080 33.71 29.97 2D to 3D,Side by Side, Top and Bottom HDTV 1080p
