ENGLISH
34
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
“ ” refers to alternating current (AC), and “ ” refers to direct current (DC).
OLED screen Screen type Thin Film Transistor (TFT)
OLED Screen
Operating conditions Daily usage 18 hours (video)
Video signal Maximum resolution HDMI / DisplayPort: 3840 x 2160 @ 30 Hz
- This may not be supported on some OS or graphics
card types.
Recommended resolution HDMI / DisplayPort: 1920 x 1080 @ 60 Hz
- This may not be supported on some OS or graphics
card types.
Horizontal frequency HDMI/ DisplayPort: 30 kHz to 83 kHz
Vertical frequency HDMI/ DisplayPort: 50 Hz to 60 Hz
Synchronization Separate Sync/Digital
Input/ Output ports USB 2.0 IN1/2, HDMI IN, DP IN/OUT, LAN IN/OUT, IR IN, RS-232C IN/OUT, AUDIO OUT
Embedded battery Applied
Environmental Conditions Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity 10 % to 80 %
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 5 % to 85 %
OLED Panel Pixel Pitch 0.630mm (H) X 0.630mm (V)
Power Rated Voltage AC 100-240 V ~ 50/60 Hz 3.7 A
Power Consumption On Mode: 309 W (Typ.)
Sleep Mode (HDMI, DisplayPort): ≤ 3.0 W
Off Mode: ≤ 0.5 W
Dimensions (Width x
Height x Depth) / Weight
Display 1220.3mm x 696.8mm x 4.9mm / 6.6kg
(48.0 inches x 27.4 inches x 0.1 inch / 14.5 lbs)
Signage Box 782.8mm x 238.4mm x 34.7mm / 3.4kg
(30.8 inches x 9.3 inches x 1.3 inches / 7.4 lbs)
