Appendix 63
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption 12 W
Dimensions (W x H x D) Approx. 430 x 41 x 188 mm (16.9 x 1.6 x 7.4 inches)
Net Weight (Approx.) 1.6 kg (3.5 lbs)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
2CH AUDIO OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL AUDIO OUT (COAXIAL) 0.5 V (p-p), 75 Ω, RCA jack x 1
System
Laser Semiconductor laser
wavelength 405 nm / 650 nm
Signal system Standard NTSC color TV system
Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio More than 90 dB (ANALOG OUT connectors only)
Harmonic distortion Less than 0.02%
Dynamic range More than 95 dB
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna) IEEE 802.11b/g/n (2.4GHz band)
Bus Power Supply (USB) DC 5 V
0
500 mA
y
Design and specications are subject to change without notice.

LG BP320 Specifications

General

Depth	198.1 mm
Width	429.3 mm
Height	40.64 mm
Weight	1814 g
Full HD	Yes
Device type	Blu-Ray player
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS 2.0
Package weight	2631 g
Cables included	AV
AC input voltage	120 V
AC input frequency	60 Hz
Disc types supported	BD, BD-R, BD-RE, BD-ROM, CD, CD-R, CD-ROM, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-ROM, DVD-RW
Playback disc formats	Blu-Ray video, CD audio
Supported video modes	1080p
Card reader integrated	No
USB 2.0 ports quantity	1
Audio formats supported	AAC, LPCM, MP3, WMA
Video formats supported	3GP, FLV, M4V, MKV, MPEG2, MPEG4, VOB, WMV
Digital audio coaxial out	-
Power consumption (standby)	0.5 W
Power consumption (typical)	11 W
Audio output channels	- channels
