Appendix22
Appendix
5
Specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) 202 mm x 307 mm x 315 mm
Net Weight (Approx.) 2.79 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply DC 5 V
0
500 mA
Inputs
AUX IN 2.0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
AM Tuning Range 522 to 1 620 kHz, 520 to 1 710 kHz or 522 to 1 710 kHz
Ampli er
Stereo mode 65w+65w ( 4 Ω at 1KHz, THD 10% )
CD
Frequency Response 100 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
CM4230_AU.DPANLLK ENG 7527.indd 22CM4230_AU.DPANLLK ENG 7527.indd 22 2013-03-06 9:28:092013-03-06 9:28:09
