LG CM4430 User Manual

5 Appendix
Appendix 25
Appendix
5
Specifications
General
Model CM4630 CM4530 CM4430 CM4330
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) 202 x 307 x 315 mm
Net Weight (Approx.) 3.15 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply DC 5 V
0
500 mA
Inputs
AUX IN 2,0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R) x 1
Tuner
FM Tuning Range 87,5 to 108,0 MHz or 87,50 to 108,00 MHz
Amplier
Model CM4630 CM4530 CM4430 CM4330
Stereo mode
250 W + 250 W
(3 Ω at 1 KHz,
THD 10 %)
160 W + 160 W
(4 Ω at 1 KHz,
THD 10 %)
150 W + 150 W
(4 Ω at 1 KHz,
THD 10 %)
90 W + 90 W
(4 Ω at 1 KHz,
THD 10 %)
Surround
mode
Front
250 W + 250 W
(3 Ω at 1 KHz,
THD 10 %)
160 W + 160 W
(4 Ω at 1 KHz,
THD 10 %)
150 W + 150 W
(4 Ω at 1 KHz,
THD 10 %)
90 W + 90 W
(4 Ω at 1 KHz,
THD 10 %)
Subwoofer -
180 W
(3 Ω at 1 KHz,
THD 10 %)
- -
CD
Frequency Response 100 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB

LG CM4430 Specifications

General

Bass reflex	-
Speaker type	4-way
RMS rated power	300 W
Number of speakers	2
Peak Music Power Output (PMPO)	3500 W
Type	Home audio mini system
Cassette deck	No
Product color	Black
Disc loading type	Tray
Optical disc player	Yes
Playback disc formats	CD audio
Audio formats supported	MP3, WMA
Apple docking compatibility	Not supported
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power source	AC
Volume control	Rotary

Weight and Dimensions

Depth	352 mm
Width	668 mm
Height	302 mm
Weight	9560 g
