CIRCUIT VOLTAGE CHART

1. CAPACITORS 2. CONNECTORS

3-69 3-70

Location

Value

Capacitor

(uF)

Voltage_Spec

100 V-10 %

240 V/50 Hz+10 %

Measured

voltage

Measured

voltage

SMPS Board

C904 330 uF 45 0V 395 V 395 V

C911 100 uF 50 V 13.5 V 13.8 V

C930 68 uF 450 V 138 V 336 V

C932 22 uF 50 V 14 V 14.5 V

C936 1000 uF 16 V 5.65 V 5.68 V

C956 470 uF 16 V 5.1 V 5.08 V

C957 100 uF 16 V -5 V -5 V

C958 100 uF 16 V 12 V 12 V

C964 220 uF 25 V 11.99 V 11.98 V

C966 2200 uF 80 V 66.5 V 66.5 V

C968 2200 uF 80 V 66.5 V 66.5 V

No Pin Pin Name Spec. Input Voltage Output Voltage

SMPS <-> MAIN CN901 (SMPS) CN106 (MAIN)

5 -5 V -5 -4.98 -4.96

7,8 +5.6 V 5.6 5.63 5.64

11 14 VA 14 12.86 12.68

12 12 V 12 11.91 11.84

14 -B (-PVDD) -58 -58 -58.1

15 GATE -54 -54.11 -54.13

SMPS <-> MAIN CN902 (SMPS) CN110 (MAIN)

1,2 +B (+PVDD) 58 65.81 65.81

5,6 -B (-PVDD) -58 -66.08 -66.08

FRONT <-> MAIN CN315 (FRONT) CN605 (MAIN)

7 FL- -25 -24.84 -24.87

14 VKK -27 -27.14 -27.15

15 FL+ -22 -22.46 -22.45

16 3.3V 3.3 3.37 3.35

24 12V 12 11.83 11.87

MAIN <-> FRONT (USB) CN502 (MAIN) CN314 (FRONT)

2,3 5.6 VA 5.6 5.64 5.64

MAIN <-> BT Module CN504 (MAIN) BT Module

10 3.3 VA 3.3 3.329 3.329

MAIN <-> Pick-up (MD) CN400 (MAIN) MD

8 DVCC_5V 5 5.01 5.01

MAIN <-> FAN Module

CN603, CN604

(MAIN)

FAN Module

1 12 V 12 11.83 11.85

FRONT <-> CTRL_A CN311 (FRONT)

CN301

(CONTROL)

6 12 V 12 11.82 11.82

Location

Value

Capacitor

[u]

SPEC

[V]

-20 %

(88 V, 60 Hz)

+20 %

(288 V, 60 Hz)

Voltage [V] Voltage [V]

C209 4.7 u 50 V 2.02 2.02

C226 100 u 16 V 11.31 11.32

C231 100 u 16 V 5.00 5.00

C238 220 u 16 V 3.30 3.30

C240 220 u 6.3 V 1.26 1.26

C308 47 u 16 V 5.21 5.21

C344 47 u 16 V 5.01 5.01

C345 47 u 16 V 5.64 5.64

C347 470 u 10 V 3.37 3.38

C402 100 u 16 V 5.00 5.00

C404 47 u 16 V 3.32 3.32

C409 47 u 16 V 3.32 3.32

C416 47 u 16 V 1.66 1.66

C418 3.3 u 50 V 0.52 0.51

C427 220 u 16 V 8.73 8.73

C501 220 u 10 V 3.23 3.23

C5C9 1000 u 6.3 V 3.35 3.36

C5E1 47 u 16 V 3.36 3.35

C604 47 u 16 V 5.12 5.12

C622 470 u 16 V 2.77 2.77

C627 47 u 50 V 27.04 27.09

C707 1000 u 80 V 65.84 65.84

C728 1000 u 80 V 65.56 65.58

C752 2200 u 80 V 65.98 65.98

C798 2200 u 16 V 66.08 66.08

C904 330 u 450 V 394.50 394.50

C926 47 u 50 V 15.72 15.74

C927 47 u 50 V 17.10 17.20

C936 1000 u 16 V 5.65 5.65

C937 2200 u 16 V 5.66 5.66

C944 470 u 25 V 12.64 12.70

C948 220 u 25 V 7.00 6.92

C958 100 u 16 V 11.83 11.84

C963 1000 u 25 V 16.17 16.18

C964 220 u 25 V 11.81 12.02

C966 1000 u 80 V 66.10 66.07

C968 1000 u 80 V 65.58 65.84
