40
GUIDE ASSEMBLY
1.
Disconnect wiring to the harness.
2.
Remove 3 screws.
3.
Pull out the guide assembly.
2.
With a flat blade screwdriver, press the tabs
on the side of frame body and gently take it
out.
FRAME BODY & LID
1.
Open the top cover.
