SPECIFICATIONS
(Only EC93**)
Wireless module(LGSBW41) Specifications
Wireless LAN Bluetooth
Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 3.0
Frequency
Range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz (for Non EU)
Frequency
Range
2400 to 2483.5 MHz
Output
Power
(Max.)
802.11a: 13 dBm
802.11b: 15 dBm
802.11g: 14 dBm
802.11n - 2.4 GHz: 16 dBm
802.11n - 5 GHz: 16 dBm
Output
Power
(Max.)
10 dBm or Lower
-y Because band channel used by the country could be different, the user can
not change or adjust the operating frequency and this product is set for the
regional frequency table.
-y This device should be installed and operated with minimum distance 20 cm
between the device and your body. And this phrase is for the general statement
for consideration of user environment.
52
SPECIFICATIONS
