LG LMC1575ST Service Manual

4-2
CONTROL PANEL
1
4
12
11
10
2
3
6
5
9
8
10
12
11
7
1. SMART DIAGNOSIS: Hold the mouthpiece of a phone up to this
icon when directed to by service center personnel, to help
diagnose problems with the oven when calling for service.
2. DISPLAY: The Display includes a clock and indicators to tell you
time of day, cooking time settings, and cooking functions selected.
3. SENSOR COOK: Touch this key to cook bacon, fresh vegetables,
frozen entrees, frozen vegetables, oatmeal, potatoes, and rice.
4. SENSOR REHEAT: Touch this key to reheat beverages,
casseroles, dinner plates, pie, and pizza.
5. SENSOR POPCORN: Touch this key to pop popcorn.
6. DEFROST: Touch this key to select food type and defrost food by
weight.
7. POWER LEVEL: The microwave oven is equipped with 10 power
levels for maximum flexibility and control over cooking. The
Microwave Power Levels section contains suggestions for which
power level to use when preparing various foods.
8. COOK TIME: Touch this key to manually set a desired cook time.
9. TIMER ON/OFF: Touch this key to set a kitchen timer.
10. MORE / LESS: Set cooking time and weight. Lengthen or
shorten the cooking time at any point by pressing the key.
(Not available in Defrost mode.)
11. STOP / CLEAR: Touch this key to stop the oven or to clear all
entries except time of day.
12. START / ENTER: Touch this key to start a function, accept
selections, or resume cooking if the door was opened or the
STOP button was pressed once.
Pressing START without setting a cook time activates the Quick
Start feature. Each press of the START button adds 30 seconds
to the cooking time.

LG LMC1575ST Specifications

General

Style	counter top
Color	stainless steel
Total Capacity	1.5 cu. ft.
Convection	no
Power Levels	10
Sensor Cooking	yes
Quick Start	no
Timer	yes
Interior Light	yes
Microwave Power	1, 250 watts
Voltage	120 volts
Current	15a

Weight and Dimensions

Depth	17 inch
Height	12 13/100 inch
Width	21 41/100 inch
