LG LN54 series User Manual

27
CAUTION FOR USING EZSIGN 2.0
ENGENGLISH
CAUTIONFORUSINGEZSIGN2.0
Only 32/37/42/47LN549E

Do not remove a USB drive while data is being copied. It can corrupt the data and EzSign may not work
properly.

While loading a USB device or dongle, your TV may function slower than normal.

While EzSign contents is running, the movie with internal subtitles is not supported in USB mode. EzSign
TV supports only external subtitles.
(External Subtitle format: *.smi/*.srt/*.sub(MicroDVD, Subviewer 1.0/2.0)/*.ass/*.ssa/*.txt(TMPlayer)/*.
psb(PowerDivX)

Some user-created subtitles may not work properly.

Some special characters are not supported in subtitles.

HTML tags are not supported in subtitles.

Subtitles in languages other than the supported languages are not available.

EzSign 2.0 TV function does not work before completing the initial setup Wizard. Make sure to complete
the initial setup Wizard by turning on the TV after installation.

If the time is set according to the TV signal, it may not appeared exactly for some region. In that case, set
the time manually.

It is recommended that you copy files to the TV memory before playing them, as playing directly from the
USB memory for an extended period of time may cause the device to overheat.

In EzSign 2.0 TV mode, some remote control keys may not work.

EzSign 2.0 TV dose not support the USB HUB. It is recommended that you connect a USB device directly
to the TV without using a USB extension cable as it may not work properly.

It is recommended that you use EzSign 2.0 TV within 8 hours per day as it is standard.

Refer to the EzSign 2.0 Editor user guide for details.

EzSign 2.0 TV does not support Store Demo.
