ENGLISH
22
MAKING CONNECTIONS
HDMI to DVI connection
Transmits the digital video signal from an external device to the TV. Connect the external device and the TV
with the HDMI to DVI cable as shown in the following illustration. To transmit an audio signal, connect an
optional audio cable.
DVD / Blu-Ray / HD Cable Box /
HD STB / Gaming device
(Not Provided) (Not Provided)
If you do not use an optional external speaker, connect the external device to the TV with the optional
audio cable.
NOTE

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG M2252D and is the answer not in the manual?

LG M2252D Specifications

General IconGeneral
3DNo
Pixel pitch0.248 x 0.248 mm
Aspect ratio16:9
Display diagonal21.5 \
Display technologyLED
Vertical scan range56 - 75 Hz
Horizontal scan range30 - 83 kHz
Contrast ratio (dynamic)5000000:1
Display number of colors16.78 million colors
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
Audio systemInfinite Surround
TV tuner integratedYes
Analog signal format systemPAL, SECAM
USB hub version2.0
DVI-D ports quantity0
Product colorBlack
Market positioning-
RMS rated power10 W
Number of speakers2
Tilt angle range-5 - 20 °
Panel mounting interface100 x 100 mm
AC input voltage100 - 240 V
Power consumption (standby)0.3 W
Power consumption (typical)30 W
Power consumption (PowerSave)1 W
Package depth126 mm
Package width578 mm
Package height384 mm
Package weight4900 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)182.8 mm
Height (with stand)386.5 mm
Weight (with stand)3600 g
Depth (without stand)62.9 mm
Width (without stand)508.6 mm
Height (without stand)314.8 mm
Weight (without stand)3100 g
