MULTI F MAX BD UNIT
Dimensions
Figure 30:PMBD3620, PMBD3630, PMBD3640, and PMBD3641 External Dimensions.
1-31/32
1-3/16
4-3/8
Min 1-3/16
Min 15-3/4
Min 15-3/4
(Servicing space)
(Side view)
(Bottom view)
Unit: inch
1-31/32
1-31/32
1-31/32
1-31/32
1-23/32
1-31/32
1-31/32
1-31/32
2-7/32
1-1/2
Main Pipe
Cover ControlBranch Pipe
2-3/8 11 -7/8
17
2-27/32
5-5/8 + 13/32* x 2
Inspection opening
23-5/8
9-27/32 or more
23-5/8
(EEV service)
(Controller service)
AB CD
Ø3/4
Ø3/8
Suspension bolt pitch.
*PMBD3641: D connections
- Ø3/8, Ø5/8
Liquid Pipe: Ø1/4
Gas Pipe: Ø3/8
9-7/16
13-9/32
ABCD
298(1 1-23/32)11-23/32
252(9-29/32) + (10(13/32)* x 2)9-29/32 + 13/32* x 2
Notes
1. PMBD3620 unit supplied with "A, B"
2. PMBD3630 unit supplied with "A, B, C"
3.PMBD3640, PMBD3641 unit supplied with "A, B, C, D"
4. * Thickness of insulation
BD UNIT | 335
Branch Distribution (BD) Unit Data
Due to our policy of continuous product innovation, some specications may change without notication.
