Getting Started
17
n
Note
When you need to remove the SIM Card, slide
it, as shown, and take it out of the socket.
4. To insert the battery, align the golden
contacts of the battery with the
corresponding connectors on the battery
compartment. Press down on the opposite
end of the battery until it snaps into place.
5. Attach back cover by sliding the bottom
into position and pressing on the edges
until they click into place.
Charging the Battery
Use of unauthorized accessories could
damage your phone and void your warranty.
To use the travel charger provided with your
phone:
1.
With the battery in position in the phone,
connect the lead from the travel charger
to to charger port on the right side of the
phone.
2.
Connect the travel charger to a standard AC
wall outlet. Only use the travel charger that
comes with the package.
