Connect your mouse to the USB port. Use the mouse to move the pointer on the TV
screen and select the menu you want.
The right button and the special buttons on the mouse do not work.
When using a wireless USB mouse, the connection can be lost or slowed, depending on
the distance between the TV and mouse and the wireless environment.
Using a USB Wired/Wireless Keyboard
Connect your keyboard to the USB port. You can enter text with the connected keyboard
device.
It is not possible to enter text on some screens.
It is recommended that you use a product that has been tested for compatibility with LG
TVs.
Logitech K360, Logitech K400, Logitech K750
You can change the input language by pressing the language switch key or the right Alt
key, And also can change by pressing the Ctrl key and the Space key at same time.
When using a wireless USB keyboard, the connection can be lost or slowed, depending on
the distance between the TV and keyboard and the wireless environment.
To enter text in the text field, use the on-screen keyboard on your TV screen or a USB
keyboard.
Using a Gamepad
Connect your gamepad to the USB port on the TV if the game requires a gamepad.
It is recommended that you use a product that has been tested for compatibility with LG
TVs.
Sony DualShock 4, Sony DualShock 3, Microsoft Xbox 360 Controller, NVIDIA SHIELD
Controller, Logitech F310, Logitech F710
Connecting Bluetooth Input Devices
You can connect and use devices such as a Bluetooth-enabled keyboard, mouse, or a
gamepad with your TV.
To see the details, click the Settings External Devices Connect Bluetooth
Controller in User Guide.
32

Table of Contents

Other manuals for LG OLED48C36LA

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG OLED48C36LA and is the answer not in the manual?

LG OLED48C36LA Specifications

General IconGeneral
StandYes
App storeLG Content Store
Picture modeVivid, Standard, Eco, Cinema, Sports, Game, Filmmaker, (ISF)Expert(Bright Room), (ISF)Expert(Dark Room)
Country of originSouth Korea
Digital audio out1
Wall mounting kitNo
USB ports quantity3
DisplayPorts quantity0
Headphone connectivity3.5mm / Bluetooth
Annual energy consumption91.323 kWh
Tuner typeAnalog & digital
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version5.0
Dimming typePixel Dimming
Game featuresAuto Low Latency Mode (ALLM), Game Dashboard, Game Optimizer, HGiG, Variable Refresh Rate (VRR)
Processor cores4
Audio formats supportedAAC, AC3, AC4, EAC3, HE-AAC, MP2, MP3, PCM, WMA, apt-X
Picture processing technologyLG AI Picture Pro
High Dynamic Range (HDR) technologyDolby Vision, High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Energy efficiency scaleA to G
Power consumption (sleep)0.5 W
Power consumption (typical)65.7 W
Package typeBox
Package depth162 mm
Package width1373 mm
Package height735 mm
Package weight20500 g
Processorα9 AI Processor 4K Gen6
Sound technologyAI Sound Pro (Virtual 9.1.2 Up-mix)
Sound modesAI Sound Pro, Clear Voice Pro
Audio decodersDolby Atmos
RMS rated power40 W
Number of speakers-
Audio output channels2.2 channels
Cables includedAC
Remote control typeMagic Remote
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)SimpLink
Screen shapeFlat
Response time- ms
Display diagonal48 \
Display brightness- cd/m²
Display technologyOLED evo
Native aspect ratio16:9
Native refresh rate100 Hz
Display diagonal (metric)120.7 cm
Motion interpolation technologyOLED Motion
Stand typeCenter stand
Product colorBlack
Music appsAmazon Music, Apple Music, BBC Sounds, Deezer, Spotify, TIDAL
Video appsAll 4, Amazon Prime Video, Apple TV, BBC iPlayer, BritBox, Chili, DAZN, Disney+, Freeview Play, ITV Hub, My5, NOW TV, Netflix, Rakuten TV, Twitch, YouTube
Smart modesCinema, Energy saving, Filmmaker, Standard, Vivid
Sports appsDAZN, Sports Alerts
Operating system version23
Operating system installedWeb OS
Weight and Dimensions IconWeight and Dimensions
Stand width470 mm
Depth (with stand)230 mm
Height (with stand)675 mm
Weight (with stand)16800 g
Depth (without stand)46.9 mm
Width (without stand)1071 mm
Height (without stand)618 mm
Weight (without stand)14900 g
