LG RHT397H User Manual

8
a
11
/ I (POWER button)
Switches the unit ON or OFF.
b Disc Tray
Insert a disc here.
c OPEN/CLOSE (Z)
Opens or closes the disc tray.
d Display window
Shows the current status of the unit.
T/S: Indicates the timeshift mode.
REC: The unit is recording.
HDD: The unit is in HDD mode.
DVD: The unit is in DVD mode.
HDD bBDVD: The unit is dubbing.
: Indicates when the unit is in timer recording or a timer recording is pro-
grammed.
: Indicates clock, total playing time, elapsed time, title number,
chapter/track number, channel, etc.
e Remote Sensor
Point the remote control here.
f N / X (PLAY / PAUSE)
Starts playback.
Pause playback or recording temporarily,
press again to exit pause mode.
g x (STOP)
Stops playback or recording.
h z (REC)
Starts recording. Press repeatedly to set the recording time.
i RES. (Resolution)
Sets the output resolution for HDMI and COMPONENT OUTPUT jacks.
- HDMI: 576i, 576p, 720p, 1080i, 1080p
- COMPONENT: 576i, 576p
j DVD
Set the recorder’s mode to DVD.
k HDD
Set the recorder’s mode to HDD.
l USB Port
Connect a USB Flash memory.
m DV IN
Connect the DV output of a digital camcorder to the HDD/DVD recorder.
n AV IN 3 (VIDEO IN/AUDIO IN (Left/Right))
Connect the audio/video output of an external source (Audio system, TV/
Monitor, VCR, Camcorder, etc.).
Main Unit
ab jckdefghi
lm n
RHT399H/RHT398H/RHT397H
ab cdefghijk
RHT389H/RHT388H/RHT387H
lm n
RH387M-P_MHEG_ENG 8/28/08 2:41 PM Page 8

LG RHT397H Specifications

General

Audio formats supported	MP3
Video formats supported	DivX
Progressive scan output	Yes
Device type	DVD recorder
HDD capacity	160 GB
Disc types supported	DVD-RAM
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	1
Dimensions (WxDxH)	430 x 49 x 275 mm
Power consumption (standby)	1 W

Weight and Dimensions

Weight	3740 g
