Appendix44
Appendix
6
Specifications
General
Power Supply
Refer to the main label or refer to the main label on the bottom
Power consumption
AC adapter DA-18B12
Dimensions (W x H x D) Approx. 110 x 29 x 110 mm (4.3 x 1.1 x 4.3 inches)
Net Weight (Approx.) 0.28kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (OPTICAL) 3 V (p-p), Optical jack x 1
System
Signal system Standard NTSC color TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna) IEEE 802.11b/g/n (2.4 GHz band)
Bus Power Supply (USB) DC 5 V
0
500 mA
y
Design and specifications are subject to change without notice.
