25
①①
Disassemble the top plate assembly.
②②
Pull out the drawer to arrow direction.
③③
Unscrew 2 screws.
①①
Disassemble hose and its clamps.
󳡊󳡊
Disassemble ventilation bellows and water inlet
bellows on the tub.
Option
DISPENSOR ASSEMBLY
DRAWER
DISPENSER ASSEMBLY
