30
① The back cover is removed.
② Two screws are unscrewed.
③ Disconnect connector from the wiring.
④ Pull the PWB assembly (Main) to arrow
direction.
① The plate assembly(Top)and the
cover(lnner)are disassembled.
② Pull the drawer to arrow direction.
③ Two screws are unscrewed.
① The hose clamps and the hose are
disassembled.
② The ventilation bellows are disassembled on
the tub.
To Next Page
