LG WD-12320(5)RD User Manual

① The cabinet cover clamp is removed and the
gasket is released.
② Two screws are unscrewed.
③ The door lock S/W is disconnected form the
wiring connector and the strap.
① Remove washing heater.
② Remove the foreign object(wire,coin,etc) by
inserting long bar in the hole.
SWITCH ASSY, DOOR LOCK
WHEN FOREIGN OBJECT STUCK BETWEEN DRUM AND TUB
Hole
Washing Heater
36
