5-4. Explanation of each process
No. noitanalpxEssecorP
1.
Stay • Electrical power is supplied.
• Washer is ready to work and the micom is in the active mode.
2.
Water
supply
• After loading laundry and selecting a course and a cycle, water is
supplied and drum rotates.
• When a user selects Pre-wash course, water is supplied through pre
wash valve.
3.
Soaking
and washing
laundry
• To get laundry wet, drum rotates clockwise and counterclockwise.
• If water amount is insufficient at this time, the Inlet valve will supply
water again.
4.
Heating and
washing
• The heater heats the water in drum to the selected water temperature
and drum rotates for washing.
5.
6.
Washing
and heating
/ washing
• When the water temperature reaches to the selected temperature,
the heating stops and only the drum rotates.
• If water temperature becomes lower than selected because of
re-supplied water, the heating starts again.
7.
Washing • Fuzzy logic decides washing time according to the laundry load, water
temperature, and other factors.
8.
Drainage • A pump motor drains the water from the drum.
• After sensing drained water amount by water level frequency, spin starts.
• When a heating course is selected, stay cooling process is performed to
decrease the water temperature gradually to prevent laundry from being
damaged and for safety reasons.
9. Untangling
(Sensing
eccent-
ricity)
• It balances laundry load and senses the eccentricity of the load, to only
allow spinning without vibration.
• If the eccentricity is worse than the allowed level, it repeats the
disentangling process. When the repeated time is more than allowed
level, it displays UE.
• If the eccentricity is good, the intermittent spin starts.
• During this process, the drain pump works for drainage intermittently.
To Next Page
