8-1. FILTER ASSEMBLY (LINE FILTER)
8. COMPONENT TESTING INFORMATION
When Resistance (Ohm) checking the Component, be sure to turn the power off,
and do voltage discharge sufficiently.
WARNING
Wiring
diagram
Circuit in the MAIN PWB / Wiring Diagram
Vac
MAIN PWB
ASSEMBLY
FUSE
RD1WH1
LI L2
RICI
C2
C3
3
2
1
3
2
1
Test
points
and
Result
Test Points Result
WH (1) to RD (3)
WH (3) to RD (1)
0 Ω
0 Ω
(3)
(1)
WH1
(3)
(1)
RD1
34

LG WM4270HVA Specifications

General

Type	Front Load Washer
Capacity	4.5 cu. ft.
Color	Graphite Steel
Energy Star Certified	Yes
Spin Speed	1300 RPM
Number of Wash Programs	14
Steam Technology	Yes
SmartThinQ (Wi-Fi)	Yes
TurboWash	Yes
Allergiene Cycle	Yes
Width	27 inches
Cycle Time	Varies by cycle
