LG WT-R107 Service Manual

3. OPERATING INSTRUCTION
10
3-1. IDENTIFICATION OF PARTS
HOT WATER SUPPLY
HOSE
COLD WATER SUPPLY
HOSE
Make sure the water
does not leak.
Powder detergent
Box for delayed
washing/softener additves box
INLET HOLE FOR
BLEACH
TUB
BASE
LEVELLING LEGS
Use to level the washing
machine for correct balance
& spin operation.
DRAIN HOSE
Check if the drain hose
is hung up before
operating the
washing machine.
FUNCTION SELECTOR
POWER PLUG
If the supply cord is
damaged,it must be
replaced by the
manufacturer
or its service agents
or similarly qualified
person in order to
avoid a hazard.
Clean regularly to stop
linting on the clothes
load.
Multi Clean filter
Washing Wing
(unique with lnner Tub)
Body
