40
4-8. TROUBLE SHOOTING METHODS ACCORIDNG TO ERROR MESSAGE
For more detailed information for trouble shooting refer to page 42 to 51.
ERROR
WATER
SUPPLY
DRAINAGE
UNBALANCE
DOOR
OPEN
WATER LEVEL
dose not rise to
the set level in 40
minutes.
Water is not
completely
drained in 13
minutes.
Laundry
unbalance during
spin.
LID is opened in
course of
operation or
processing reser
vation.
1. Drain hose is hung on to
drainage which is 0.9m
above from floor.
2. Water faucet is closed?
3. Water supply is interrupted.
4. Inlet V/V is clogged with
dirts.
5. Connector has bad contact
to the inlet valve.
6. BLUE 6 pin connector has
bad contact to the P.W.B
ASM.
1. Is the drain hose located
properly?
2. Drain hose is folded or
clogged due to freeze or dirt.
3. Bad Drain Pump part or
BLUE (WHITE) 2 pin
connector to the P.W.B ASM
has bad connection.
1. Laundry in the INNER TUB
is filled unevenly.
2. Washer is tilted.
1 Lid is opened during
intermittent spin or normal
spin?
2 Lid is opened while
processing reservation?
3. Bad lead wire ASM or
Connector to the Lid S/W or
RED 4pin connector to the
P.W.B ASM has bad
connection.
1. Hang drain hose which is
minimum 0.9m above from
floor.
2. Open water faucet.
3. Wait until water supply is
resumed.
4. Clean or replace filter.
5. Correct the connector
contact.
6. Same as above.
1. Hung up drain hose at
0.9~1.2m high.
2. Unclose the foreign objects
within drain hose.
3. Replace Drain Motor or
correct the connector
contact.
1. Try to fill laundry uniformly in
the inner tub.
2. Adjust the leg.
1. Closed the lid.
2. Closed the lid.
3. Check and replace Lead
Wire ASM or Correct the
connector contact.
ERROR DECISION
BASIS
CAUSE FOR ERROR
OCCURRENCE
REMEDY
To Next Page
